Sungrow SBH battery - 5kWh modular unit

Sungrow SBH battery - 5kWh modular unit

https://www.acsolarwarehouse.com/web/image/product.template/25309/image_1920?unique=b719a6d

SBH200/ 250/300/350/400


    This combination does not exist.

    Login or Register to view prices and place an order

    Volume pricing will be automatically applied for:

    1+ pallets, 4+ pallets and 10+ pallets


    SKU: SBH200/ 250/300/350/400

    Sungrow SBH Battery - 5kWh


    Each 5kWh battery module is designed for exceptional reliability and efficiency, seamlessly integrating into both residential and commercial energy systems. The system's flexible configuration supports a minimum of 4 modules and up to a maximum of 8 per stack, depending on the connected inverter.

    You can parallel up to 4 stacks, achieving a total storage capacity of 160kWh, providing scalable solutions tailored to your specific energy needs.

    With the capability of up to 50A continuous charge and discharge currents, the SBH Series ensures consistent power output, maintaining reliable operation even during peak demand periods. These battery modules offer ample energy reserves to support high-power applications effortlessly.

    Ideal for residential backup power or commercial energy management, Sungrow's SBH Series sets the benchmark for reliability, efficiency, and scalability in energy storage.

    To install the Sungrow SBH battery - 5kWh modular unit you need the Sungrow SBH battery - Accessory kit


    Specifications Sungrow SBH battery - 5kWh

    • Battery Type: Lithium iron phosphate
    • Maximum Storage Capacity: 5kWh per module
    • Continuous Charging and Discharging: 50A
    • Dimensions: 675 x 160 x 350 mm
    • Weight: 45 kg
    • Warranty: 10 years


    Configuration Requirements:


    Modules per Stack:

    • Minimum: 4 modules

    Parallel Stacks:

    • Up to four equal stacks can be connected in parallel to a single inverter.
    • Requirement: SJR050-04 Combiner is necessary for connecting stacks in parallel.

    Accessory Requirements:


    Design and Expansion:


    The system is stackable and modular, allowing for easy expansion by adding more modules within the specified limits.


    Example Configurations:


    SH5.0/6.0RS System:

    • Stack can have between 4 to 5 modules.

    SH8.0/10RS System:

    • Stack can have between 4 to 6 modules.

    SH5.0/10RT System:

    • Stack can have between 4 to 7 modules.

    SH15/20/25T System:

    • Stack can have between 4 to 8 modules.

    For each of these configurations, ensure the use of the SBH Accessory Kit for each tower and consider the necessity of the SJR050-04 Combiner for parallel connection of up to four stacks to a single inverter.
