Sigenergy Power Sensor Three Phase with CT 100A

Sigenergy Power Sensor Three Phase with CT 100A

SKU: Sigen Sensor TP-CT100

The Sigenergy Power Sensor is a high-accuracy energy detection device designed for precise control in three-phase systems. It features 1% high-accuracy power detection for precise system control and is engineered with a compact size and plug-in design for easy installation. The sensor integrates smoothly with other Sigenergy devices, requiring no additional setup. For flexible communication, the sensor has optional WiFi halow remote communication functionality when used with the Sigen Sensor Sub1G Kit. When paired with the Sub1G Kit, it supports stable data transmission up to 200 m.

Key Features Sigenergy Power Sensor Three Phase with CT 100A:

• High Accuracy Monitoring: Provides 1% high-accuracy power detection.

• Seamless Integration: Integrates smoothly with Sigenergy devices, requiring no setup.

• Simple Installation: Features a compact IP size and plug-in design for easy installation via DIN Rail 35 mm.

• Optional Long-Range Wireless: Supports efficient and stable data transmission up to 200 m when utilizing the Sigen Sensor Sub1G Kit.

• Three-Phase Compatibility: Designed for 3P3W and 3P4W grid connection types.


Sigenergy Power Sensor Three Phase with CT 100A Basic Specs:

• Grid Connection Type: 3P3W/3P4W

• Max Operating Current: 100 A

• Power Accuracy: 1%

• Nominal AC Frequency: 50/60 Hz

• AC Input Voltage Range (L-N): 176-276 Vac

• Ingress Protection (IP) Rating: IP20

• Installation Method: DIN Rail 35 mm

• Communication Interface: RS485 (Modbus RTU)


What’s Included:

• Sigen Power Sensor unit (TP-CT1002 model)
• 3 x CTs (Current Transformers)

• Max operating current of CTs: 100 A

• CT Cable Length: 1 m

• CT Inner Diameter: 24/16 mm
