SolarEdge Home Hub Universal Inverter - 5kW production limit (single phase)
10kW Inverter factory locked to 5kW for CEC/DNSP requirements (becomes a 10kW inverter in backup mode)
SolarEdge Wireless Gateway and 70A CT included in box
SolarEdge Energy Meter and Home Network comms built-in
Hybrid inverter compatible with up to 3 SolarEdge Home Batteries
SolarEdge Backup Interface required for backup functionality
SolarEdge Optimisers required to connect PV
Receive a free Home Hub Universal Inverter when adding a single-phase battery and backup interface package to an existing SolarEdge single-phase system.
Program ends on 30th June 2026. Learn more.
SolarEdge Home Hub Universal Inverter - 5kW production limit (single phase)
SKU: SE5000H-AUSNKBY14
The SolarEdge Home Hub Universal Inverter with a 5kW production limit is an advanced energy manager designed specifically for Australian and New Zealand homes. This single-phase solution provides high efficiency and supports future upgrades for EV charging and DC-coupled storage.
Backup-ready inverter
When pairing the Home Hub Universal Inverter with the SolarEdge Home Battery and Backup Interface, in the event of grid interruption, provide homeowners with backup power for either full or partial home loads. It offers record-breaking weighted efficiency of 99% and allows for significant DC oversizing to maximize energy yield even with a 5kW AC output limit.
Key Features SolarEdge Home Hub Universal Inverter - 5kW:
- Record-Breaking Efficiency: Achieves 99% weighted efficiency, ensuring high energy production over the system's life.
- DC-Coupled Storage: Supports high-efficiency DC-coupled battery storage for improved performance.
- Integrated Management: Acts as a central manager for PV production, battery status, and self-consumption data with built-in monitoring.
- Advanced Safety: Includes built-in SafeDC™, rapid shutdown, and integrated arc fault protection (AFCI) for maximum site safety.
- Built-in Metering: Comes with an integrated import/export meter and a supplied Current Transformer (CT) for immediate visibility.
- Smart EV Ready: Compatible with SolarEdge Home EV Chargers for integrated home energy and transport management.
- Durable Construction: IP65-rated design suitable for both indoor and outdoor installations in diverse climates.
SolarEdge Home Hub Universal Inverter - 5kW Basic Specs:
- Rated AC Power: 5,000 VA.
- Maximum AC Power Output: 5,000 VA.
- Maximum Inverter Efficiency: 99.2%.
- Maximum DC PV Power: Up to 300% DC oversizing (limited by model configuration).
- Nominal DC Input Voltage: 380 Vdc.
- Protection Rating: IP65.
- Operating Temperature Range: -40 to +60 degrees Celsius.
- Dimensions (H x W x D): 540 x 370 x 185 mm.
- Weight: Less than 20 kg.
What’s Included:
- 1 x SolarEdge Home Hub Universal Inverter (5kW production limit model).
- 1 x Integrated communication kit for SolarEdge Home Network and Wi-Fi.
- 1 x Built-in import/export meter.
- 1 x Current Transformer (CT) for monitoring.
- 1 x Standard 12-year warranty (extendable to 25 years).
